Gen5 Amplifier

Please call for price

The AMTI Gen 5 provides industry-leading performance and innovative features in an easy-to-use and cost effective package.

STATE-OF-THE-ART SIGNAL CONDITIONING

  • Provides six independently configurable data channels
  • Fully calibrated and NIST-traceable
  • Signal conditioning includes: 1 kHz anti-aliasing filters, oversampling and digital signal processing
  • Built-in cable length compensation
  • Provides internal crosstalk correction by applying a factory calibrated platform correction matrix
  • Tested to medical-grade standards for safety, essential performance and electro-magnetic compatibility

HEART OF NEW SMART PLATFORM SYSTEM

  • Provides plug and play interface for AMTI force plates and force sensors
  • Applies complete transducer profile stored onboard all new AMTI force plates and force sensors, including bridge resistance, transducer capacity and calibration matrix
  • Allows users to order their platforms by simply walking across them in subjects’ direction of travel

INTUITIVE AND EASY TO USE

  • Fully software configurable
  • All calibration and configuration settings stored internally
  • Automatic balancing of strain gage bridges initiated by front-panel button or by software
  • Supports both genlock data acquisition and external triggering
  • Multiple Gen 5’s automatically synchronize data sampling – no additional wiring required.

DIGITAL AND ANALOG OUTPUTS

  • Gen 5 can be connected to a PC or other data acquisition system via the digital (USB) or analog output
  • Factory calibrated gain and offset correction constants applied to each output channel
  • Each of the six analog output channels has an independent 16-bit DAC conditioned by a low-pass reconstruction filter and amplifier.
  • Digital output stream consists of fully processed IEEE floating point numbers presented in their respective engineering units.

HIGHLY CONFIGURABLE

  • Software-selectable excitation (2.5, 5.0, and 10.0 volts)
  • Software-selectable gains (500, 1000, 2000, and 4000)
  • Software-selectable zero set point

FLEXIBLE INTEGRATION

  • NetForce: complete data acquisition solution – features multi-channel real time acquisition and display, including center of pressure
  • Gen 5 Setup Program: easy integration with analog systems and third-party software applications
  • Gen 5 Software Development Kit: available for incorporating Gen 5 amplifiers into proprietary systems

Contact us today at hello@logemas.com for more information.
